The Moog D136-001-007 is a high-performance motion controller belonging to the MOOG MSC III series. Here are the detailed contents:
- Manufacturer: Moog (穆格)
- Product Type: Motion controller
- Control Type: Closed-loop control
- Input Voltage Range: 12 - 48VDC
- Output Voltage Range: 5VDC
- Output Current: Maximum of 10A
- Communication Interfaces: Support various communication interfaces such as fieldbus (e.g., EtherCAT, PROFINET), Ethernet, RS232/485. It also supports multiple communication protocols like PROFIBUS DP and Modbus.
- Position Sensor Interfaces: Encoder, analog quantity, SSI
- CPU: 32-bit RISC processor
- Dimensions: 170mm x 105mm x 32mm
- Weight: Approximately 120g
- Operating Temperature: -20°C to +50°C
- Storage Temperature: -40°C to +70°C
- High-performance Control: With powerful processing capabilities and fast response speeds, it can achieve high-precision and high-dynamic-performance motion control, enabling precise position, speed, and force control.
- Integrated PLC Function: It integrates programmable logic controller (PLC) functions, which simplifies system design and programming, and supports logic control, sequence control, etc..
- Flexible Programming: Supports IEC 61131-3 standard programming languages, making it convenient for users to develop and debug programs.
- Multi-axis Control: Can support up to 30 axes for closed-loop control, and can handle complex multi-axis functions, realizing multi-axis coordinated motion control, such as linear/circular/helical interpolation functions.
- Self-diagnosis Function: Equipped with a perfect self-diagnosis function, which can monitor the operating status of the module to ensure the reliability of the system.
- Industrial Automation: Widely used in metal forming (such as controlling presses, bending machines, and shearing machines), plastic machinery (such as controlling injection molding machines, extruders, and blow molding machines), and automation assembly (such as controlling robots and automated production lines).
- Testing Equipment: Used to control material testing machines, fatigue testing machines, vibration testing machines, etc., for precise control and data acquisition during the testing process.
- Servo Control Systems: Applicable to servo-hydraulic control (controlling hydraulic cylinders, hydraulic motors, and hydraulic servo valves), servo-electric control (controlling servo motors, linear motors, and electric cylinders), and hybrid control applications that integrate hydraulic and electric control systems.
