Hardware Specifications

• Processor: Some sources indicate it may be equipped with an Intel Atom E3845 1.91 GHz quad-core processor, while others mention a high-performance dual-core processor. There is also a description stating it is a 32-bit processor module with an 80C186 processor, but the former two seem more in line with typical modern industrial controller configurations.
• Memory: It usually has 4 GB DDR3L - 1333 SDRAM, and some versions may have 8 GB DDR4 RAM. The storage capacity is typically 32 GB SSD, although there are also records of 128 GB SSD.
• Communication Interfaces: It is equipped with 2 x 10/100/1000 Mbps Ethernet ports, 2 USB 2.0 ports, 1 USB 3.0 port, and 2 RS-232/422/485 serial ports. Some versions may also have 4 Gigabit Ethernet ports.
• I/O Interfaces: There are 16 digital inputs, 16 digital outputs, 4 analog inputs, and 4 analog outputs, which can be used to connect with various sensors and actuators.
• Power Supply: The power supply voltage is 24 VDC ±10%, and the power consumption is 10 W.
• Physical Dimensions: The dimensions are 50 x 100 x 100 mm (W x H x D), and the weight is 0.5 kg. However, there is also a different size record of 89mm x 32mm x 100mm with a weight of 0.25kg, which may be for a different version or model variation.
• Operating Environment: The operating temperature range is 0 to 50°C, the storage temperature range is -20 to 60°C, and the humidity tolerance is 10 to 95% RH (no condensation).

Programming and Features

• Programming Interface: The CPU-30ZBE provides flexible programming interfaces and development tools, supporting multiple programming languages and development environments. This allows users to customize development and application writing according to their specific needs.
• Control Capabilities: It can support multi-axis control, enabling the simultaneous control of multiple motion axes to realize complex multi-axis collaborative motion control. It also adopts advanced control algorithms to achieve precise motion control and positioning.

Applications

• Industrial Automation: It is widely used in factory automation systems, such as packaging and labeling systems, conveyor belts, and other industrial equipment for precise control and monitoring.
• Robotics and Machinery: It can be used as the core component of robot control systems to realize the precise movement and positioning of robots. It is also applicable to CNC machines and other precision machinery for motion control, data acquisition, and system monitoring.
• Other Applications: It is suitable for material handling equipment, machine tools, test and measurement equipment, and can also be integrated into building management systems for controlling lighting, heating, ventilation, and security systems.
