Basic Information

• Product Model: B&R 7CP476.60-1
• Product Category: Industrial Communication Module (EtherCAT Master/Slave Module)
• Manufacturer: B&R Industrial Automation GmbH
• Application Scope: Industrial automation systems, CNC machine tools, robotic arms, and automated production lines (compatible with B&R Automation PC and PLC systems for high-speed data exchange)

Technical Specifications

1. Communication Protocol: EtherCAT (IEC 61158), supports CoE (CANopen over EtherCAT)
2. Communication Ports: 2 x RJ45 Ethernet ports (100 Mbps, full-duplex); 1 x HDMI port (for display output)
3. Operating Voltage: 24 V DC ±10%; Typical current consumption ≤ 0.8 A
4. Operating Conditions: Temperature range 0°C to +60°C; Humidity 5%–95% (non-condensing); Vibration resistance ≤ 5g (10–2000 Hz)
5. Mechanical Specifications: DIN rail mounting (35mm); Dimensions 45mm × 120mm × 100mm; Weight approx. 250g
6. Protection & Certifications: Overvoltage, short-circuit protection; Compliance with IEC 61010-1, CE, UL standards

Core Functions & Features

• High-speed EtherCAT communication, enabling real-time data transmission with cycle times down to microseconds
• Supports both master and slave modes, flexible for different network topology requirements
• Seamless integration with B&R Automation Studio software for intuitive configuration and diagnostics
• Built-in status LED indicators for power, communication, and fault, facilitating quick troubleshooting
• Compact modular design, saving installation space in control cabinets and supporting system expansion
• Robust anti-interference performance, adapting to complex electromagnetic environments in industrial sites
