- Manufacturer: Honeywell
- Product Type: Digital Output (DO) Module
- Number of Output Channels: 32 (independent channels for flexible control)
- Output Type: Transistor (NPN)
- Rated Output Voltage: 24VDC
- Maximum Output Current: 0.5A per channel
- Surge Current Withstand Capacity: 1A per channel (duration < 10ms)
- Response Time: Typical value for both ON to OFF and OFF to ON switching is 0.1ms (enables high-speed logic control and precise timing).
- Isolation Voltage: 500VDC (between channels, and between channels and the system; enhances anti-interference capability).
- Protection Functions: Integrated short-circuit protection and overload protection (safeguards the output circuit and on-site equipment from damage).
- Operating Temperature: -40°C to +70°C (adapts to harsh industrial environments).
- Storage Temperature: -40°C to +85°C.
- Relative Humidity: 5% to 95% (non-condensing).
- Power Consumption: Typical value of 5W (low energy consumption for system efficiency).
- High Channel Density: 32 independent output channels reduce the cost per output point, save system space, and simplify wiring.
- High-Speed Response: Rapidly switches output states according to PLC commands, meeting the requirements of high-speed logic and precise timing control (e.g., fast-paced production lines).
- Reliable Solid-State Output: Adopts transistor output with no mechanical contacts, no wear, long service life, and high reliability (avoids contact bounce issues of mechanical switches).
- Built-In Protection: Short-circuit and overload protection prevent damage caused by abnormal current, ensuring stable operation of the module and on-site devices.
- Reliable Isolation Protection: Electrical isolation between channels and between channels and the system minimizes interference from external electrical noise (critical for complex industrial power environments).
- Easy Integration and Configuration: Seamlessly integrates with the ControlEdge™ PLC system; configuration and parameter setting can be performed simply and intuitively via dedicated configuration tools (reduces deployment time).
- Robust Design: Withstands harsh industrial conditions (wide temperature range, humidity resistance) for long-term stable operation.
Used to control switch-type actuators such as relays, solenoid valves, contactors, and indicator lights. Typical applications in industrial automation include:
- Equipment start/stop control (e.g., motor on/off for production machinery).
- Valve control (e.g., opening/closing of control valves in process pipelines).
- Indication and alarm (e.g., status indicator lights for equipment or fault alarms).
- Contactor and relay control (e.g., triggering intermediate relays for high-power device control).
- Conveyor belt control (e.g., starting/stopping conveyor lines in logistics or assembly processes).
- Packaging machinery control (e.g., controlling sealing, cutting, or feeding mechanisms in packaging lines).
- Mounting Method: DIN rail mounting (compatible with standard 35mm DIN rails for standardized cabinet installation).
- Pre-Installation Checks:
- Ensure the installation environment meets the module’s operating conditions (temperature, humidity).
- Inspect the module’s appearance for damage and check the wiring terminals for looseness.
- Confirm that the on-site actuator’s voltage/current specifications match the module’s output ratings (avoid overloading).
- Regular Inspections:
- Check connecting wires for tightness (prevent poor contact due to vibration).
- Clean dust from the module and surrounding areas (avoid dust accumulation affecting heat dissipation or causing short circuits).
- Verify the stability of the power supply and grounding (ensure reliable electrical connections).
- Fault Handling:
- Monitor the module’s indicator lights (for status or fault signals).
- If a fault occurs (e.g., no output, overload alarm), contact professional personnel for inspection and repair (do not disassemble the module without authorization).
