The Honeywell 82408217-001 is a versatile industrial control module designed for critical applications in manufacturing, energy, and process automation. Based on verified technical documentation and specifications from authorized distributors, here's a detailed breakdown:
- Brand: Honeywell
- Model: 82408217-001
- Product Type: High-Performance Control Module
- Application: Textile machinery, printing presses, rubber/plastics processing, woodworking, and general industrial automation.
- Function: Executes real-time control algorithms, manages I/O signals, and interfaces with distributed control systems (DCS) or programmable logic controllers (PLCs).
SIL 3 Certification:
- Ensures safety-critical applications meet the highest integrity standards, particularly for motor control systems .
High-Precision I/O:
- 16 digital inputs/outputs support direct connection to sensors, switches, and actuators (e.g., solenoid valves, motor starters) .
Real-Time Diagnostics:
- Proactive fault detection (e.g., open-wire detection, signal discrepancies) with LED indicators for power, communication, and channel health .
Modular Design:
- Easy installation via DIN rail or panel mounting in standard 19-inch enclosures .
Hazardous Location Compliance:
- Certified for use in explosive environments (ATEX/IECEx) when paired with compatible accessories .
Advanced Control Algorithms:
- Supports sensorless vector control for induction motors and permanent magnet motors up to 599 Hz .
- Motor Control: Speed regulation, torque control, and soft starting for pumps, conveyors, and industrial machinery.
- Process Automation: Batch processing, quality inspection, and machine status monitoring.
- Energy Management: Power plant diagnostics, renewable energy systems (e.g., solar pump drives), and grid integration .
- Safety Interlocks: Emergency shutdown (ESD) systems, access control, and fire/gas detection integration.
- Wiring: Terminal blocks for power and I/O connections (supports 24–14 AWG wires) .
- Mounting: DIN rail or panel-mountable in standard 19-inch enclosures.
- Configuration:
- Use Honeywell’s Control Builder software or third-party tools supporting Modbus RTU for programming and I/O mapping .
- Redundancy:
- Optional dual-channel redundancy setup for failover protection (requires additional modules) .
- User Manuals: Available on Honeywell’s official support portal, detailing wiring diagrams, configuration steps, and troubleshooting (e.g., Industrial Control Module User Guide) .
- Datasheets: Technical specifications, pinouts, and compliance certifications (e.g., Honeywell 82408217-001 Datasheet) .
- Software Tools:
- Honeywell Control Builder: For developing control logic using IEC 61131-3 languages (e.g., ladder logic, structured text).
- Modbus Master/Slave Utilities: For testing communication with third-party devices .
- Model Variants:
- The 82408217-001 is part of Honeywell’s modular I/O series, with variants supporting analog I/O (e.g., 8C-PAIHA1) or expanded communication protocols .
- Power Calculation:
- Total power consumption depends on the number of active I/O channels. Ensure the power supply meets the system’s requirements .
- Third-Party Compatibility:
- Verify Modbus RTU register addresses and baud rates with non-Honeywell systems (e.g., Emerson DeltaV, Siemens SIMATIC) during integration .
For precise technical details and compliance information, consult Honeywell’s official product documentation or contact their Industrial Automation Support Team.
