Honeywell CC-PAIH01 High-Level Analog Input Module with HART

General Information

• Brand: Honeywell
• Model: CC-PAIH01
• Product Type: High-Level Analog Input Module
• Compatibility: Honeywell Experion PKS, C300 Controller, and TDC 3000 systems.

Technical Specifications

• Power Supply: 24 VDC (from system backplane).
• Input Type:
  • Current: 4–20 mA (via 250 Ω resistor), 0–20 mA
  • Voltage: ±10 V, ±5 V, ±2.5 V, ±1 V (configurable).
• HART Support: HART 7 protocol (point-to-point & multidrop; up to 15 devices per channel).
• Number of Channels: 16 (12 single-ended, 4 differential).
• Resolution: 16-bit A/D converter.
• Accuracy: ±0.1% of full scale (current/voltage inputs).
• Isolation: 1,500 VAC (channel-to-channel).
• Input Scan Rate: Configurable (typical 50 ms per channel).
• Common Mode Voltage: -6 to +5 V peak.
• Normal Mode Rejection: 19 dB at 60 Hz.
• Operating Temperature: -40°C to +85°C.
• Environmental Rating: IP20 (dust protection).
• Dimensions: 125 mm x 100 mm x 35 mm.

Key Features

1. HART Communication:
   • Simultaneous analog (4–20 mA) and digital HART communication for device configuration, diagnostics, and remote monitoring.
   • Multidrop capability supports up to 15 HART devices per channel.
2. High-Precision Signal Acquisition:
   • 16-bit resolution ensures accurate measurement of voltage and current signals.
   • Configurable input ranges for flexibility in sensor integration.
3. Channel Isolation & Noise Immunity:
   • 1,500 VAC channel isolation prevents signal interference in harsh environments.
   • Advanced filtering reduces noise from electromagnetic sources.
4. Redundancy & Hot-Swap Support:
   • Compatible with redundant systems for high availability.
   • Online replacement (hot-swappable) minimizes downtime.
5. Diagnostics & Status Monitoring:
   • Per-channel LED indicators for signal status, faults, and module health.
   • Open wire detection and self-diagnostics for quick troubleshooting.

Applications

1. Process Control:
   • Oil & gas: Monitoring pipeline flow, tank levels, and reaction parameters.
   • Power generation: Collecting data from generators, transformers, and switchgear.
2. Manufacturing:
   • Automotive and electronics production lines for equipment monitoring and quality control.
3. Building Automation:
   • Smart buildings: Environmental sensors (temperature, humidity) and HVAC system optimization.
4. Chemical & Pharmaceutical:
   • Precise control of reactor conditions and compliance with regulatory standards.

Documentation & Support

• Datasheet: Available via Honeywell’s official technical support portal (requires registration)sps.honeywell.com.
• Warranty: Typically 12 months from the date of purchase.
• Technical Assistance: 24/7 global support for configuration, troubleshooting, and firmware updatessps.honeywell.com.

Installation Notes

• Termination: Requires Honeywell’s IOTA (Input/Output Termination Assembly) for field wiring.
• Configuration: Configured via Honeywell’s Experion PKS engineering tools or HART communicators.
• Safety Compliance: Meets CE and CSA standards for industrial use.
