The HIMA F6706 is a 2-fold analog output module. Here is the detailed information:
- Manufacturer: HIMA.
- Type: Analog output module.
- Country of Origin: Germany.
- Weight: 0.32 kg.
- Dimensions: 4 cm x 18.5 cm x 12.8 cm.
- Dual-channel Output: It has 2 isolated analog output channels, which can provide outputs of 0/4 - 20 mA. Each channel is individually galvanically isolated and has safety isolation, and can operate in either source or sink mode.
- High Safety Level: The module is tested according to AK6/SIL3 standards, ensuring high safety and reliability in safety-critical applications.
- Self-diagnosis Function: All modules are equipped with a self-diagnosis function for fault detection, which can quickly identify and report faults to ensure the normal operation of the system.
- High-precision Output: With a resolution of 12 bits, it can achieve high-precision analog output, meeting the needs of various industrial control applications for precise control.
- Output Current: 0/4 - 20 mA.
- Output Voltage: 5 - 24 V DC.
- Power Consumption: Typical 25 mA.
- Operating Temperature: -25 °C to +85 °C.
- Relative Humidity: 0% to 95% non-condensing.
- Communication Interface: Modbus RTU.
- Clock Frequency: 28 mhz.
- Space Requirement: 5.2 te.
The HIMA F6706 is widely used in various industrial fields, including chemical process control, oil and gas extraction and processing, power generation and distribution, metallurgy and material processing, pharmaceutical and biotechnology, environmental protection and water treatment, etc. It can be used to control various industrial processes, such as the opening and closing of valves, the speed regulation of motors, and the adjustment of temperature, pressure, and flow.
