The HIMA F3322 is a digital output module belonging to the HIMatrix F30 input/output series. Here is the detailed information:
The F3322 is mainly used to control external devices such as valves, motors, and relays in safety instrument systems (SIS). It is widely used in safety - critical applications due to its high reliability, high availability, and rich functions.
- High Reliability: It adopts redundant design and self - diagnosis function to ensure reliable operation of the system under extreme conditions.
- High Availability: The modular design makes it easy to maintain and replace, improving the availability of the system.
- Rich Functions: It provides various output types, such as relay output and transistor output, to meet different application requirements.
- Safety Certification: It complies with SIL 3 certification, suitable for safety - critical applications.
- Flexible Configuration: It can be flexibly configured through software to adapt to different system requirements.
- Power Supply Voltage: 24V DC
- Output Current: Max. 250mA per channel
- Number of Channels: 16
- Response Time: In the millisecond range
- Operating Temperature: 0°C - 50°C
- Relative Humidity: 5% - 95%
- Protection Class: IP20
- Communication Interface: RS485
- Relay Contact Type: SPST (Single Pole Single Throw)
- Operating Frequency: Up to 2kHz
- Dimensions: 20.3cm x 12.7cm x 2.5cm
- Weight: 0.2kg
The installation method is DIN - rail mounting, which is convenient for installation and wiring in the control cabinet. The modular design also makes maintenance and replacement of the module very convenient.
The F3322 is widely used in the safety instrument systems of petroleum, chemical, electric power, pharmaceutical, food and other industries, such as safety interlocking systems, emergency shutdown systems in the petrochemical industry, and substation automation, power plant safety protection systems in the electric power industry.
