The Westinghouse 1C31192G01 is a module applied in industrial control systems, and it has different functional versions. Here is a detailed introduction based on the information from relevant websites:
- General Information
- Brand and Model: The brand is Westinghouse, and the model is 1C31192G01.
- Type: It is an industrial control module, which may have different specific types according to different application scenarios, such as digital input module, analog input module, speed detection module, etc.
- Certification: Some versions are certified to CE, UL, and CSA standards, ensuring safety and compliance with international regulations.
- Physical Characteristics
- Dimensions: Usually, its dimensions are about 12.1 x 5.1 x 16.6 cm, with a compact design, which is suitable for installation in occasions with limited space.
- Weight: The weight is about 0.35 kg, which is lightweight, making it easy to handle and install.
- Functional Characteristics
- As an Analog Input Module: It is part of the Westinghouse Ovation distributed control system (DCS) and is used to measure analog input signals from external devices. It has 4 channels, and each channel can be configured for different analog input types, such as current (4 - 20 mA) and voltage (0 - 10 V). The input accuracy is ±0.1% full - scale, the input resolution is 0.01% full - scale, the input impedance is >100 kΩ, and the response time is <2 seconds.
- As a Digital Input Module: It is designed to meet the demanding requirements of modern industrial control systems and can provide precise control and monitoring capabilities. It supports an operating voltage of 220 V and operates at an output frequency of 50 kHz.
- As a Speed Detection Module: It is used to measure the rotational speed and offers unparalleled accuracy and reliability in speed measurement. The operating range is 0 - 10,000 rpm, and the accuracy is ±0.1% of the reading. The detection distance can be up to 200 mm, and the signal output can be 4 - 20 mA or PWM. It has a wide operating temperature range of - 20 °C to +70 °C, with an environmental rating of IP67, and it uses Modbus communication protocol.
- Indicator Lights
- I/O Module Indicator Lights: "P" (green) indicates that the module power is normal when the module power is supplied normally; "C" (green) indicates that the module communication is normal when the controller communication is normal and the communication time monitor has no communication timeout; "E" (red) is the external fault indicator light, which lights up when the module has external problems, such as a blown fuse of the common auxiliary power supply; "I" (red) is the internal fault indicator light, which lights up when a fault occurs inside the module, and in general, the electronic module needs to be replaced when this light is on.
- Controller LED Indicator Lights: Green - power indicates that the DC power is operating normally; red - fault indicates that there is a fault; green - working state indicates that the controller is operating as the main controller; green - standby indicates that the controller is operating as the standby controller; yellow flashing - main control network indicates that the main control network is working normally; yellow flashing - 副 control network indicates that the 副 control network is working normally. Except for the power supply, the alternate flashing of the remaining indicator lights indicates a hardware upgrade.
It should be noted that there may be some differences in specific functions and parameters due to different versions and application scenarios. For more accurate and detailed information, it is recommended to refer to the official technical documentation of Westinghouse or consult relevant technical personnel.
