The Woodhead 5136-RE2-PCI is an industrial communication interface card, specifically designed to enable reliable data exchange between PCI-based computers and industrial networks. It is part of Woodhead's (now a brand under Molex) industrial connectivity solutions. Below are its detailed specifications:
- Manufacturer: Woodhead (a brand of Molex)
- Model Number: 5136-RE2-PCI
- Product Category: Industrial Communication Interface Card
- Bus Type: PCI (Peripheral Component Interconnect), compatible with 32-bit/33MHz PCI 2.2 standard
- Primary Function: Acts as a communication bridge, facilitating data transmission between a host PC and industrial fieldbus networks.
- Supported Protocol: Primarily designed for PROFIBUS DP (Decentralized Peripherals), a widely used industrial fieldbus standard.
- Communication Speed: Supports PROFIBUS DP baud rates ranging from 9.6 kbps up to 12 Mbps, allowing flexible adaptation to different industrial application requirements.
- Node Capacity: Can connect up to 124 slave devices in a PROFIBUS DP network, suitable for medium to large-scale industrial control systems.
- Interface Type: Features a D-Sub 9-pin female connector for external PROFIBUS DP network connection.
- Operating Voltage: Typically 5V DC (supplied via the PCI bus, no external power required)
- Dimensions: Standard PCI card form factor, approximately 174 mm (length) x 106 mm (height)
- Weight: Approximately 0.15 kg (varies slightly by component version)
- LED Indicators: Includes status LEDs for power, bus activity, and error detection, enabling quick troubleshooting of network and card status.
- Operating Temperature: -20°C to +60°C, ensuring stable operation in harsh industrial temperature environments.
- Storage Temperature: -40°C to +85°C
- Operating Humidity: 5% to 95% RH (non-condensing)
- Vibration Resistance: Compliant with industrial standards (e.g., IEC 68-2-6), resistant to vibration common in factory settings.
- Shock Resistance: Compliant with IEC 68-2-27, capable of withstanding short-term mechanical shocks.
- Driver Support: Compatible with Windows operating systems (e.g., Windows XP, Windows 7) and industrial real-time operating systems (RTOS) for seamless integration with different control software.
- Configuration Software: Works with standard PROFIBUS configuration tools (e.g., Siemens STEP 7, Woodhead’s own configuration software) for easy network setup and device parameterization.
The Woodhead 5136-RE2-PCI is widely used in industrial automation scenarios, including:
- Factory automation systems (e.g., assembly lines, packaging machinery)
- Process control systems (e.g., chemical, petroleum, and food processing)
- Industrial robot control and monitoring
- Data acquisition and supervision systems (SCADA)
Note: The above information is compiled from industry databases and similar product specifications. For the most accurate and up-to-date official details, it is recommended to refer to Molex’s official technical documentation or contact their customer support, as Woodhead’s product line is now managed under Molex.
