The IC755CSW07CDA is an operator interface terminal (HMI module) from GE Fanuc's VersaMax series, primarily used to enable human-machine interaction in industrial automation systems. It facilitates operators in monitoring equipment status, modifying parameters, and executing control commands. Below is its detailed information:
- Display: 7-inch color TFT screen with a resolution of 800×480 pixels, supporting 256 colors for clear visual presentation.
- Processor & Memory: 32-bit processor, equipped with 128MB RAM and 128MB flash memory, ensuring smooth interface operation and stable data storage.
- Communication Interfaces:
- 1 Ethernet port (10/100 Mbps) for network communication with PLCs, SCADA systems, and other devices.
- 2 RS-232/RS-485 serial ports, connectable to printers, barcode scanners, or other serial devices.
- 1 USB port (Type A) for data transfer, program downloading, or connecting external storage devices.
- Power Requirement: 24 VDC input, with a power consumption of approximately 12W.
- Operating Environment:
- Operating temperature: 0°C to 50°C
- Storage temperature: -20°C to 60°C
- Humidity: 10% to 90% RH (non-condensing)
- Protection rating: IP65 (front panel), suitable for industrial on-site environments.
- Mounting: Panel-mounted design, saving space and facilitating integration into control cabinets or equipment panels.
- Intuitive Human-Machine Interaction: Operated via a color touchscreen, supporting touch and swipe gestures. The interface is customizable, displaying real-time data, trend graphs, and alarm information to help operators quickly grasp system status.
- Multi-Protocol Compatibility: Supports mainstream industrial communication protocols such as Modbus RTU/TCP and EtherNet/IP, enabling seamless connection with GE Fanuc series PLCs (e.g., VersaMax, 90-30/70) and automation equipment from other brands.
- Data Logging & Alarming: Equipped with data logging functionality to record key process parameters and operation logs. Supports multi-level alarm settings; alarm information is highlighted on the screen with audible alerts to ensure timely detection of abnormalities.
- Easy Programming & Maintenance: Interface configuration is done via GE's Proficy Machine Edition software, supporting graphical programming for quick design of personalized operation interfaces. Supports remote monitoring and program updates to reduce maintenance costs.
- Industrial-Grade Reliability: Features a rugged housing design with strong resistance to vibration and electromagnetic interference, adapting to complex industrial environments with dust and humidity for long-term stable operation.
- Local monitoring and operation of production line equipment, such as packaging machinery, assembly lines, and conveying systems.
- Human-machine interaction terminal for small to medium-sized industrial control systems, used for parameter setting, status monitoring, and fault diagnosis.
- Operation interface for water treatment, HVAC (Heating, Ventilation, and Air Conditioning), and power distribution systems, enabling centralized management.
- Works with PLCs to provide an intuitive operation platform in automated equipment for industries such as food and beverage, pharmaceuticals, and automotive parts.
- Compatible with GE Fanuc VersaMax series PLCs and mainstream PLCs from other brands (e.g., Siemens, Rockwell), enabling data exchange via standard communication protocols.
- Integrates with SCADA software such as Proficy iFIX and Cimplicity, 融入 upper-level monitoring systems.
- Connects to peripherals like barcode scanners and printers for data collection and output functions.
