Hardware Configuration

• Microprocessor: Based on Intel Pentium II or 80486DX4 microprocessor, with a clock frequency of 96MHz.
• Memory: Equipped with 1MB battery-backed CMOS RAM to ensure no data loss in case of power failure, and 256KB non-volatile user flash memory for storing user programs and data.
• Communication Interfaces: Has 3 independent serial ports, supporting communication protocols such as RS-485 and RS-232; in addition, it supports Ethernet connection, facilitating data exchange with other devices or systems.

Performance Parameters

• I/O Points: Supports up to 12K discrete I/O and 8K analog I/O, which can meet the I/O point requirements of large-scale industrial control systems.
• Floating-Point Operation: Supports floating-point operations, capable of executing complex mathematical operations and control algorithms, suitable for scenarios with high requirements for calculation accuracy.

Functional Features

• BMA Support: Supports BMA (Basic Motion Application) function, which can be used in motion control applications and realize precise control of motion equipment such as motors.
• Programming and Configuration: Uses single-slot programming software under Windows or MS-DOS for configuration and programming, supporting multiple programming languages including ladder diagram, structured text, instruction list and custom function blocks.

Physical Characteristics

• Dimensions: Approximately 150mm x 200mm x 60mm.
• Weight: Approximately 1.5 kg.
• Operating Temperature Range: -10°C to 55°C.

Application Fields

• Motion Control: Can be used in high-precision motion control systems, such as the control of machine tools, robots and other equipment.
• Data Acquisition: Suitable for high-speed data acquisition and processing systems, capable of quickly collecting a large amount of I/O data.
• Process Control: Widely used in industrial processes that require complex calculation and control, such as the continuous production process control in chemical, pharmaceutical and other industries.
