The 5X00226G01 is an I/O interface module manufactured by Emerson, which belongs to the Ovation control system. The detailed introduction is as follows:
This module is responsible for processing analog input signals and supports hot swapping, allowing on-line replacement without affecting system operation. It can convert analog signals from on-site devices (such as sensors and transmitters) into digital signals, which are then transmitted to the controller for processing. This enables precise monitoring and control of parameters like temperature, pressure, and flow rate.
- Input Signal Types: Supports multiple analog signals such as 4-20mA and 0-10V.
- Number of Channels: Typically 8 or 16 channels, depending on the model configuration.
- Accuracy: Up to ±0.01% or higher, ensuring the accuracy of signal conversion.
- Sampling Rate: Up to 10ms per channel, meeting the requirements of high-speed data acquisition.
- Isolation Characteristics: Electrical isolation between channels to prevent signal interference.
- Operating Temperature Range: -40°C to +70°C.
- Power Requirements: 24VDC, with optional redundant power supply.
- Protection Level: IP20, requiring installation in a control cabinet.
- High Reliability: Adopts a redundant design and fail-safe mechanism to ensure stable system operation in harsh environments.
- Modular Design: Supports hot swapping for easy maintenance and upgrading.
- Self-Diagnostic Function: Real-time monitors the module status and provides fault early warning.
- HART Communication Support: Enables simultaneous transmission of analog and digital information to realize intelligent device management.
- Compliance with Industrial Standards: Has passed certifications such as CE, UL, and CSA, meeting industrial safety requirements.
Widely used in automated control systems across industries including power, petroleum, chemical engineering, metallurgy, and water treatment. It is suitable for applications requiring high-precision analog input, such as boiler control, steam turbine monitoring, and pipeline pressure monitoring.
