The Schneider 140CPS12400 is a power supply module of the Modicon Quantum series. Here is its detailed information:
- General Information
- Manufacturer: Schneider Electric
- Model: 140CPS12400
- Type: PLC power supply module
- Compatibility: Designed for Modicon Quantum and Modicon Premium PLC systems
- Mounting: Din-rail mounted
- Electrical Specifications
- Input Voltage: 115/230V AC (auto-ranging, 85 – 264V AC wide input)
- Frequency: 47 – 63Hz
- Output Voltage: 24V DC (regulated)
- Output Current: 20A max (continuous operation)
- Power Rating: 480W
- Efficiency: ≥85%
- Protection & Safety Features
- Short-circuit Protection: Automatic shutdown & auto-recovery
- Overload Protection: Thermal protection with auto-reset
- Overvoltage Protection: Safeguards connected PLC components
- Isolation: Input-to-output isolation (3000V AC, 1 min)
- Environmental & Mechanical Ratings
- Operating Temperature: -25°C to +70°C
- Storage Temperature: -40°C to +85°C
- Humidity: 5 – 95% RH (non-condensing)
- Vibration Resistance: 5g @ 10 – 150Hz (IEC 60068-2-6)
- Shock Resistance: 30g @ 11ms (IEC 60068-2-27)
- Certifications & Compliance
- Safety Standards: UL 508, CSA C22.2 No. 14, EN 61131-2
- EMC Standards: EN 61000-6-2 (immunity), EN 61000-6-4 (emissions)
- Industrial Certifications: CE, RoHS, REACH compliant
- Indicators & Diagnostics
- LED Status Indicators: Pwr (green) for input power ok; Ok (green) for output voltage normal; Fault (red) for overload/short-circuit detected
- Physical Dimensions
- Dimensions (W × H × D): 140 × 125 × 115mm
- Weight: 2.5kg
